| Part Number | 12SR186250254 |
|---|---|
| Dimension(mm) | 27x16x6.35H |
| Rated Impedance | 4Ω±15% |
| Rated Power (W) | 1W |
| Max Power (W) | 2W |
| Resonance Frequency | 550±20%Hz |
| Output SPL | 72±3dB(1W/1M with baffle, by average of 1000,1200,1800,2000Hz) (1/12 Octave) |
| T.H.D. | 5% Max 1W/1M 1kHz |
