| Part Number | 11SR203110688 |
|---|---|
| Dimension(mm) | 18.8×9.8×3.6H |
| Rated Impedance | 4Ω±15% |
| Rated Power (W) | 1W |
| Max Power (W) | 1.2W |
| Resonance Frequency | 950±20%Hz |
| Output SPL | 93±3dB(1W/0.1M Without Barrier By Average Of 1k，2k,3k,4kHz) |
| T.H.D. | 10% Max 1 W/0.1M at 1 KHz~10KHz in 1cc back cavity |
